Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X1000-20
$148.64
Regular price
$156.14
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ40X1000-20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard cylinder compliant with internal specifications;
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
Installation Guidelines:
Mount using SAU-MF40 flange kit for vertical applications.
Maintain 0.5-1mm/m alignment tolerance during installation.
Perform stroke adjustment before pressure application - turn cushion screw clockwise to decrease cushion length.
Critical Note:
Requires monthly lubrication maintenance in high-cycle applications (>500 cycles/hour).
Not recommended for side load exceeding 15N·m or vacuum applications below -0.08MPa.
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40 Adjustable Cylinder SAUJ40X1000-20 Technical Details
- Model Code: SAUJ40X1000-20
- Cylinder Type: Adjustable stroke double-acting
- Bore Size: 40mm (ISO 6432 standard)
- Stroke Length: 1000mm ±1.5mm tolerance
- Operating Pressure: 0.05-1.0 MPa
- Cushioning: External adjustable rubber bumper (20mm adjustment range)
- Mounting Style: Basic type (no built-in mounting features)
- Port Size: Rc1/8 (G1/8 optional)
- Piston Speed: 50-800 mm/s (lubricated condition)
- Temperature Range: -10℃ to 70℃ (NBR seals)
- Rod Material: Chrome-plated carbon steel (H5 tolerance)
- Tubing Material: Aluminum alloy anodized body
- Weight: 5.2kg ±3% (without accessories)
- Dimensions: 1175mm(L) × 52mm(W) × 52mm(H) (fully extended)
- Rod Thread: M10×1.25 male thread (ISO 12240-2)
- Repeat Positioning Accuracy: ±0.5mm
High-precision long-stroke cylinder with unique dual-axis alignment design, featuring a hardened stainless steel guide rod parallel to the main piston rod for enhanced lateral load resistance. The 20mm adjustable end cushion prevents impact damage during full extension. Requires 10-30μm filtered air with ISO VG32 lubricator oil for optimal performance.
Industrial Applications:
- Palletizing robot end-effector positioning
- CNC machine tool chip conveyor actuators
- Automotive welding fixture height adjustment
- Textile machinery tension control systems
- Solar panel production line material handling
Installation Guidelines:
Mount using SAU-MF40 flange kit for vertical applications.
Maintain 0.5-1mm/m alignment tolerance during installation.
Perform stroke adjustment before pressure application - turn cushion screw clockwise to decrease cushion length.
Critical Note:
Requires monthly lubrication maintenance in high-cycle applications (>500 cycles/hour).
Not recommended for side load exceeding 15N·m or vacuum applications below -0.08MPa.
| Property | Property Value |
|---|---|
| sku | SAUJ40X1000-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
