Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X1000-30S
$151.44
Regular price
$158.94
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ40X1000-30S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard cylinder compliant with internal specifications;
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
Installation note:
Requires intermediate support for full extension (1000mm stroke) applications.
Use alignment jigs during mounting to prevent rod deflection. Lubricate every
50km of operation in dusty environments. Not recommended for vertical downward
thrust applications exceeding 50kgf.
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X1000-30S Adjustable Cylinder Specifications
- Model: SAUJ40X1000-30S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm (ISO 6432 standard)
- Stroke length: 1000mm (adjustable in 1mm increments)
- Operating pressure: 0.05–0.85 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (optional MF1/MF2 front/rear flange)
- Port size: 1/4" NPT (dual ports at both ends)
- Piston rod material: SUS304 stainless steel (chrome-plated)
- Cylinder tube: Aluminum alloy with hard anodized finish
- End caps: Extruded aluminum alloy
- Operating temperature: -20℃ to +80℃
- Weight: Approximately 8.5kg (dry)
- Dimensions: 1300mm(L) × 100mm(W) × 100mm(H) (max extended length)
- Rod thread: M12×1.75 external thread (both ends)
- Lubrication: Pre-lubricated (use ISO VG32 hydraulic oil if needed)
High-precision long-stroke cylinder with position-lock mechanism, featuring a unique anti-rotation guide design for stable linear motion. The hardened stainless steel rod and double-sealed piston ensure 2,000km service life under full load. Includes magnetic piston for sensor compatibility (NPN/PNP options).
Typical Applications:
- Automated palletizing systems
- CNC machine tool clamping devices
- Solar panel positioning mechanisms
- Automotive assembly line fixtures
- Packaging machine pusher arms
Installation note:
Requires intermediate support for full extension (1000mm stroke) applications.
Use alignment jigs during mounting to prevent rod deflection. Lubricate every
50km of operation in dusty environments. Not recommended for vertical downward
thrust applications exceeding 50kgf.
| Property | Property Value |
|---|---|
| sku | SAUJ40X1000-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
