Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X1000-40
$148.64
Regular price
$156.14
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ40X1000-40
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard cylinder compliant with internal specifications;
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
Installation note:
Maintain parallel alignment with driven components during mounting.
Requires periodic lubrication (ISO VG32 hydraulic oil recommended)
every 1,000km of cumulative travel. Avoid side-load forces exceeding 30N.
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X1000-40 Adjustable Stroke Cylinder Specifications
- Model: SAUJ40X1000-40
- Bore size: 40mm
- Stroke length: 1000mm (adjustable)
- Operating pressure: 0.1–0.9 MPa
- Cushioning type: Adjustable rubber cushion (both ends)
- Mounting style: Standard MF1/MF2 flange or foot mounting
- Rod material: Chrome-plated steel rod
- Cylinder tube: Aluminum alloy with hard anodized surface
- Seal material: NBR (nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 5.8kg ±2%
- Dimensions: 1100mm(L) × 50mm(W) × 50mm(H) (full extension)
- Port size: Rc1/4 (G1/4 optional)
- Piston speed: 50–800mm/s
- ISO standard: 15552 compliant
High-precision adjustable stroke cylinder featuring a mechanical stopper mechanism for mid-position locking. The dual-rod design ensures stability during long-stroke operations, with corrosion-resistant construction for harsh environments. Includes magnetic piston for position sensing compatibility.
Typical Applications:
- Automated production line positioning systems
- Press machine stroke adjustment mechanisms
- Packaging equipment with variable product sizes
- Material handling elevator controls
- Textile machinery tension adjustment
Installation note:
Maintain parallel alignment with driven components during mounting.
Requires periodic lubrication (ISO VG32 hydraulic oil recommended)
every 1,000km of cumulative travel. Avoid side-load forces exceeding 30N.
Stroke Adjustment:
- Loosen the hexagonal lock nut
- Rotate the adjustment screw (1 full rotation = 1.5mm stroke change)
- Tighten lock nut while maintaining adjustment position
- Verify position with limit switches or sensors
| Property | Property Value |
|---|---|
| sku | SAUJ40X1000-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
