Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X1000-40S
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X1000-40S Adjustable Cylinder Specifications
- Model: SAUJ40X1000-40S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke: 1000mm (adjustable via external stopper)
- Operating pressure: 0.1–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: Standard MF1 front flange
- Port size: G1/8 (ISO standard threads)
- Body material: Aluminum alloy with hard anodized finish
- Seal material: NBR (nitrile rubber)
- Stroke adjustment: External screw-type stroke adjustment mechanism
- Repeat positioning accuracy: ±0.5mm
- Max. piston speed: 1000 mm/s
- Weight: ~4.8kg (dry, without accessories)
- Dimensions: 1040mm(L) × 76mm(W) × 76mm(H)
High-precision long-stroke cylinder featuring external stroke adjustment with position-locking capability. The dual piston design ensures smooth operation across full stroke length, while the triple sealing system (wipers + rod seal + buffer seal) prevents leakage in high-cycle applications. Includes magnetic piston for sensor compatibility.
- Automated assembly line positioning systems
- Automotive welding fixture clamping
- Material handling elevator stops
- Packaging machine stroke adjustment mechanisms
- Machine tool workpiece positioning
Installation note:
Requires intermediate support brackets for strokes over 500mm. Lubricate rod weekly with ISO VG32 hydraulic oil.
Adjust cushioning screws while monitoring air pressure gauge (recommended 0.3-0.5MPa during tuning).
| Property | Property Value |
|---|---|
| sku | SAUJ40X1000-40S |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
