Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X1000-50S
$151.44
Regular price
$158.94
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ40X1000-50S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard cylinder compliant with internal specifications;
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
Installation guidelines:
Use C-shaped wrenches for stopper adjustment to prevent cylinder rotation.
Lubricate with ISO VG32 hydraulic oil if operating below 0.3MPa.
Maintain 0.3mm minimum clearance between stopper and cylinder end.
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40 Adjustable Cylinder SAUJ40X1000-50S Technical Details
- Model Code: SAUJ40X1000-50S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke: 1000mm (adjustable through mechanical stopper)
- Operating pressure: 0.05-1.0 MPa
- Piston rod diameter: 16mm (chrome-plated steel)
- Max thrust: 1260N @ 0.7MPa
- Speed range: 50-1000mm/s
- Mounting style: Front flange (MF1) with rear foot mounting (50S code)
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: 1/4" NPT (G1/8 optional)
- Body material: Aluminum alloy (anodized)
- Rod seal: Polyurethane (NBR option available)
- Ambient temperature: -20℃ to 80℃
- Weight: 9.8kg ±2% (without accessories)
- Dimensions: 1140mm(L) × 80mm(W) × 80mm(H) (fully extended)
- ISO standard: 15552 compliant
- Repeat positioning accuracy: ±0.5mm
High-precision long-stroke cylinder with position memory function, featuring dual shock absorption and anti-rotation guide mechanism. The hardened piston rod and double lip seals ensure reliable performance in high-cycle applications. Includes magnetic piston for position sensing compatibility.
Industrial Applications:
- Automated palletizing systems requiring variable stroke control
- Press machine tooling with position-dependent force adjustment
- Electronics assembly line pick-and-place units
- Automotive welding fixture positioning
- Packaging machine product ejection systems
Installation guidelines:
Use C-shaped wrenches for stopper adjustment to prevent cylinder rotation.
Lubricate with ISO VG32 hydraulic oil if operating below 0.3MPa.
Maintain 0.3mm minimum clearance between stopper and cylinder end.
| Property | Property Value |
|---|---|
| sku | SAUJ40X1000-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
