Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X1000-75
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40X1000-75 Adjustable Cylinder Specifications
- Model: SAUJ40X1000-75
- Type: Double-acting adjustable stroke cylinder
- Bore size: 40mm
- Stroke: 1000mm (adjustable via external stoppers)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (75mm buffer stroke)
- Port size: G1/8 (NPT1/8 optional)
- Piston rod thread: M16×1.5
- Material: Aluminum alloy barrel, hardened steel rod
- Seal material: NBR + PU combination
- Temperature range: -20℃ to 80℃
- Weight: 8.7kg (with standard mounting brackets)
- Dimensions: 1125mm(L) × 80mm(W) × 80mm(H)
- Mounting: Front flange (ISO 15552 standard)
- Lubrication: Pre-lubricated (Oil-free operation possible)
High-precision industrial cylinder with stroke adjustment mechanism, featuring dual-position locking collars for fine-tuning working length. The extended 75mm cushion chamber enables smooth deceleration at stroke ends, reducing impact noise by 30% compared to standard models. Anodized barrel surface resists chemical corrosion in harsh environments.
- Automated assembly line positioning systems
- Paper/converting machinery tension control
- Plastic injection molding ejector mechanisms
- Automotive welding fixture actuators
- Solar panel cleaning robot arms
Installation note:
For maximum stability with full stroke extension, support rod end with
guided rail when lateral force exceeds 50N. Adjust cushion screws in
1/4-turn increments during commissioning.
- Re-lubrication interval: 3 million cycles (or 12 months)
- Rod wiper replacement cycle: 5 million cycles
- Torque specs: Mounting bolts 25±3 Nm, cushion screws 1.2 Nm
| Property | Property Value |
|---|---|
| sku | SAUJ40X1000-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
