Airtac SAUJ40 Adjustable Stroke Cylinder SAUJ40X1000-75S
2. Features custom bidirectional seal profile for piston sealing with compact dimensions and integrated oil reservoir;
3. Aluminum tube with octagonal pattern design, rodless construction. Enhanced corrosion resistance; Integrated external sensor mounting grooves for simplified installation;
4. Compared to ISO 15662 standard cylinders, SAU series demonstrates shorter stroke length at equivalent bore sizes;
5. Precision-engineered smooth cushioning adjustment mechanism;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials implemented, operational range: 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SAUJ40
AirTAC SAUJ40 Adjustable Cylinder SAUJ40X1000-75S Technical Specifications
- Model Code Breakdown: SAUJ40-X1000-75S
- SAUJ: Adjustable stroke cylinder series
- 40: 40mm bore diameter
- X1000: 1000mm maximum stroke length
- 75S: 75mm rod diameter with adjustable cushioning
- Bore Size: Ø40mm (±0.02mm tolerance)
- Stroke Range: 50-1000mm (mechanically adjustable)
- Operating Pressure: 0.05-1.0 MPa
- Piston Rod: Chrome-plated steel Ø16mm
- Max Thrust: 125.6N at 0.5MPa (calculated)
- Cushioning: Adjustable air cushion at both ends
- Mounting: Standard MF1 front flange with mounting holes (4×M6)
- Port Size: G1/8 (BSPP thread)
- Ambient Temperature: -10℃ to 80℃
- Materials:
- Tube: Aluminum alloy AL6063-T5
- End caps: Die-cast aluminum
- Seals: NBR/PU combination
- Weight: 8.7kg (with max stroke)
- Dimensions:
- Length: 1215mm (min: 265mm)
- Width: 68mm (flange to flange)
- Height: 68mm (including mounting protrusions)
High-precision adjustable stroke cylinder with industrial-grade construction, designed for long-stroke applications requiring variable positioning. Features dual cushion adjustment screws with ±15° rotation range for precise deceleration control. The anodized surface treatment provides corrosion resistance in humid environments.
- Automated pallet stacking systems
- Plastic injection molding ejectors
- Textile machinery tension control
- Automotive assembly line positioning
- Woodworking CNC feed mechanisms
Installation guidelines:
For optimal performance, maintain 0.3-1.0mm alignment tolerance during mounting.
Lubricate with ISO VG32 hydraulic oil before initial operation.
Adjust cushion needles gradually - 1/4 turn increments recommended.
| Property | Property Value |
|---|---|
| sku | SAUJ40X1000-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <40mm> |
| Stroke | <1000mm> |
