Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X10-10S
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X10-10S Adjustable Cylinder Technical Details
- Model: SAUJ50X10-10S (Standard Stroke Adjustable Series)
- Bore size: Ø50 mm
- Stroke: 10 mm (Customizable: 10-300 mm)
- Operating pressure: 0.05-0.9 MPa
- Cushioning: External adjustable rubber bumper
- Mounting type: Basic style (MF1) with optional foot mounting
- Temperature range: -20℃ to 80℃
- Body material: Anodized aluminum alloy
- Rod material: Chrome-plated steel
- Seals: NBR (Nitrile) standard, optional FKM/Viton
- Port size: 1/8" NPT (G1/8 optional)
- Piston speed: 50-800 mm/s (lubricated)
- Weight: 0.85 kg (excluding accessories)
- Dimensions: 118mm(L) × 50mm(W) × 50mm(H) (at full retraction)
- Protection class: IP40 (Dust protected)
Precision-engineered compact cylinder featuring dual-directional stroke adjustment via locknut mechanism. The SAUJ series combines position stability (±0.5mm repeatability) with corrosion-resistant construction, optimized for applications requiring millimeter-level positioning control. Requires ISO VG32 turbine oil lubrication for optimal performance.
- Semiconductor wafer handling robots
- Pharmaceutical tablet pressing mechanisms
- Precision clamping in CNC fixture systems
- Automated liquid dispensing equipment
- High-speed sorting gate actuators
Installation guidelines:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations exceeding 45° angle,
use auxiliary guide mechanisms to prevent piston rod deflection. Lubricate every 3 months under normal load.
Critical note:
Avoid side load exceeding 15N·m. When used in cleanroom environments (Class 1000+),
specify optional stainless steel version SAUJ50X10-10S/SS.
| Property | Property Value |
|---|---|
| sku | SAUJ50X10-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <10mm> |
