Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-10
$73.47
Regular price
$80.97
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ50X100-10
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard pneumatic cylinder compliant with proprietary specifications;
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
Installation note:
For optimal performance, maintain 0.5mm minimum alignment tolerance between rod and load.
Lubricate with ISO VG32 hydraulic oil before initial operation. Use 40μm filtered air with
dew point -15℃ below ambient temperature. Maximum side load: 30N at full extension.
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X100-10 Adjustable Cushioning Cylinder Specifications
- Model: SAUJ50X100-10
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable)
- Operating pressure: 0.15–0.8 MPa
- Port size: Rc1/4 (NPT1/4 optional)
- Cushioning type: Adjustable rubber buffer (both ends)
- Piston rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized)
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 1.8 kg ±5%
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H) (minimum retracted length)
- Max theoretical force: 157N @0.5MPa (extend), 135N @0.5MPa (retract)
- Mounting type: Standard AF50 series foot mounting
- Protection rating: IP40 (standard seals)
Precision-engineered adjustable stroke cylinder featuring dual-side cushion control with ±3mm stroke adjustment capability. The chrome-plated piston rod incorporates a wear-resistant coating, while the aluminum body ensures corrosion resistance and heat dissipation. Includes built-in magnet for position sensing compatibility (sensor sold separately).
Typical Applications:
- Packaging machine stopper mechanisms
- Automated assembly line positioning devices
- Textile machinery tension control systems
- Plastic injection molding ejectors
- Printing press gripper adjustments
Installation note:
For optimal performance, maintain 0.5mm minimum alignment tolerance between rod and load.
Lubricate with ISO VG32 hydraulic oil before initial operation. Use 40μm filtered air with
dew point -15℃ below ambient temperature. Maximum side load: 30N at full extension.
Configuration Options:
- Rod end types: Female thread (standard), clevis, or flange
- Optional magnetic piston for position feedback (SAUJ50X100-10-M)
- High-temperature seals available (-10℃ to 120℃)
- Corrosion-resistant version with stainless steel components
| Property | Property Value |
|---|---|
| sku | SAUJ50X100-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
