Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-100
$73.47
Regular price
$80.97
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ50X100-100
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard pneumatic cylinder compliant with proprietary specifications;
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
Installation tip:
Lubricate the stopper adjustment threads with molybdenum disulfide grease before initial use.
Maintain 0.3mm minimum clearance between stopper nuts during adjustment to prevent over-compression.
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50 Adjustable Cylinder SAUJ50X100-100 Technical Details
- Model Code: SAUJ50X100-100
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50mm
- Stroke: 100mm (adjustable through stopper mechanism)
- Operating pressure: 0.05-1.0 MPa
- Cushioning type: Fixed rubber bumper + adjustable external stopper
- Port size: Rc1/4 (NPT1/4 optional)
- Piston speed: 50-750 mm/s
- Ambient temperature: -20℃ to 80℃
- Mounting style: Basic type (MF1) with front flange
- Rod end type: Female thread M16×2.0
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP54 (standard wiper design)
- Weight: 2.85 kg (without accessories)
- Dimensions:
- Extended length: 250mm
- Retracted length: 150mm
- Body diameter: Ø62mm
- Mounting hole spacing: 60mm×60mm
Heavy-duty adjustable stroke cylinder featuring dual-position locking mechanism for precise stroke control. The external stopper allows ±5mm fine-tuning without disassembly. Anodized aluminum construction with chrome-plated piston rod resists corrosion in humid environments. Includes magnetic piston for sensor compatibility.
Common Applications:
- Variable height positioning in packaging machinery
- Press-fit operations with tolerance compensation
- Modular conveyor system height adjustments
- Die casting machine ejection control
- Automated warehouse stacker positioning
Installation tip:
Lubricate the stopper adjustment threads with molybdenum disulfide grease before initial use.
Maintain 0.3mm minimum clearance between stopper nuts during adjustment to prevent over-compression.
Stroke Adjustment Procedure:
- Loosen both lock nuts on the stopper rod
- Rotate adjustment collar to desired position
- Tighten front nut to 14-16 N·m torque
- Secure back nut using counter-torque method
| Property | Property Value |
|---|---|
| sku | SAUJ50X100-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
