Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-100S
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X100-100S Adjustable Stroke Air Cylinder Specifications
- Model: SAUJ50X100-100S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable via external stopper)
- Operating pressure: 0.1–0.9 MPa
- Cushion type: Adjustable air cushion (both ends)
- Mounting style: Standard foot mounting (MF1)
- Port size: Rc1/4 (G1/4 optional)
- Temperature range: -10℃ to 80℃
- Material: Aluminum alloy body, NBR seals
- Weight: 2.8 kg (without accessories)
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H) (max extended length)
- Rod thread: M16×1.5
- Piston speed: 50–800 mm/s
- Protection rating: IP54 (standard seals)
Precision-adjustable pneumatic cylinder featuring dual external stroke adjustment screws for millimeter-level positioning accuracy. The 360° rotatable mounting base allows flexible installation in confined spaces. Equipped with wear-resistant guide bushings and chrome-plated piston rod (5μm thickness) for extended service life.
- Precision clamping fixtures in CNC machining centers
- Variable height positioning in conveyor systems
- Pressure-sensitive assembly operations
- Packaging machine stopper mechanisms
- Printing press roller engagement systems
Operation tip:
Always lubricate with ISO VG32 turbine oil (1-2 drops per port) when using non-lubricated air supply.
Lock adjustment screws with counter nuts after positioning. Avoid side loads exceeding 30N.
| Property | Property Value |
|---|---|
| sku | SAUJ50X100-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
