Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-20
$73.47
Regular price
$80.97
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ50X100-20
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard pneumatic cylinder compliant with proprietary specifications;
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
Installation guidelines:
Always degrease mounting surfaces before installation. For vertical mounting,
use auxiliary support brackets when cylinder length exceeds 300mm. Lubricate
piston rod weekly with ISO VG32 hydraulic oil in high-cycle applications (>500
cycles/hour). Avoid angular misalignment exceeding ±2° during mounting.
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X100-20 Adjustable Cylinder Technical Details
- Full model designation: SAUJ50X100-20
- Cylinder type: Double-acting adjustable stroke
- Bore size: Ø50 mm
- Stroke length: 100 mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -10℃ to 70℃
- Cushioning type: Adjustable hydraulic buffer (both ends)
- Mounting style: MF1 series basic mounting (ISO 15552 standard)
- Port size: G1/4 (BSPP thread)
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy with hard anodized surface
- Seal material: NBR (nitrile rubber)
- Weight: 2.45 kg ±3% (without accessories)
- Dimensions (L×W×H):
- Extended length: 250 mm
- Retracted length: 150 mm
- Body width: 63 mm
- Mounting height: 50 mm
- Max theoretical force (@0.63MPa):
- Thrust: 1,237 N
- Retract: 1,073 N
Precision-engineered adjustable stroke cylinder featuring dual adjustable hydraulic cushions for smooth end-of-stroke deceleration. The SAUJ series incorporates a unique mechanical stroke adjustment mechanism with locking nuts for precise position setting (±0.5mm repeatability). Anti-rotation design with integrated guide slots ensures stable linear motion under side load conditions.
Industrial Applications:
- Variable height positioning in material handling systems
- Press-fit operations requiring controlled insertion depth
- Automated assembly line clamping mechanisms
- Packaging machine product ejection systems
- Plastic injection molding machine core-pull actuators
Installation guidelines:
Always degrease mounting surfaces before installation. For vertical mounting,
use auxiliary support brackets when cylinder length exceeds 300mm. Lubricate
piston rod weekly with ISO VG32 hydraulic oil in high-cycle applications (>500
cycles/hour). Avoid angular misalignment exceeding ±2° during mounting.
Adjustment procedure:
- Loosen both cushion lock nuts (M12×1.25)
- Rotate adjustment screws (clockwise to shorten stroke)
- Test cycle 3-5 times after adjustment
- Re-tighten lock nuts to 4.5 N·m torque
| Property | Property Value |
|---|---|
| sku | SAUJ50X100-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
