Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-20S
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X100-20S Adjustable Cylinder Specifications
- Model: SAUJ50X100-20S
- Bore size: 50 mm
- Stroke: 100 mm (adjustable)
- Operation type: Double-acting
- Working pressure: 0.05–1.0 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting style: SWL series standard (ISO 15552 compatible)
- Port size: Rc1/4 (G1/4 optional)
- Piston rod thread: M16×1.5
- Ambient temperature: -20℃ to 80℃
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated steel
- Seals: NBR + PU combination
- Weight: 2.8 kg ±3%
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H) (retracted state)
- Stroke tolerance: ±1.5mm
- Max theoretical force: 1960N @ 1.0MPa
- ISO speed range: 50–750 mm/s
Precision-adjustable pneumatic cylinder featuring dual-sided position locking via micrometer-style stroke adjusters. The SAUJ series combines high rigidity with anti-rotation guidance, optimized for applications requiring mid-stroke positioning accuracy. Integrated shock absorbers reduce end-impact noise by 30% compared to standard cylinders. Requires 5-40μm filtered air with ISO VG32 lubricant.
- Variable height work platforms in assembly lines
- Press-fit component insertion systems
- Adjustable clamping fixtures for CNC machining
- Printing press roller positioning
- Automated packaging material tension control
Installation note:
Locking nuts must be torqued to 12-15N·m after stroke adjustment.
Avoid side load exceeding 50N. For vertical mounting,
use M6×12 mounting screws with Loctite 243 threadlocker.
| Property | Property Value |
|---|---|
| sku | SAUJ50X100-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
