Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-30
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X100-30 Adjustable Stroke Air Cylinder Specifications
- Full model designation: SAUJ50X100-30
- Cylinder type: Double-acting adjustable stroke
- Bore size: Ø50 mm
- Full stroke length: 100 mm
- Adjustable stroke range: 70-100 mm (±15mm fine-tuning)
- Operating pressure: 0.1–0.9 MPa
- Cushion type: Rubber buffer + adjustable stopper
- Mounting style: Basic type (no built-in mounts)
- Operating temperature: -20℃ to 80℃
- Port size: G1/8 (NPT1/8 optional)
- Piston rod material: Chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Weight: 2.35 kg (including mounting hardware)
- Dimensions:
- Extended length: 228 mm
- Retracted length: 158 mm
- Body diameter: Ø56 mm
- Rod end thread: M16×1.5
Precision-adjustable pneumatic cylinder featuring dual-position mechanical stops for mid-stroke positioning. The hexagonal adjustment nuts enable ±15mm stroke modification without disassembly. Anti-rotation design maintains orientation during partial stroke operations. Compatible with auto-switch sensors (separate purchase).
- Variable height work platforms in assembly lines
- Clamping force adjustment in CNC fixtures
- Packaging machine product height compensation
- Printing press roller engagement control
- Automated warehouse stacker positioning
Installation protocol:
Lock adjustment nuts with 8-10 N·m torque after positioning.
Lubricate with ISO VG32 hydraulic oil if used below -10℃.
Allow 20mm front clearance for stroke adjustment tools.
| Property | Property Value |
|---|---|
| sku | SAUJ50X100-30 |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
