Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-30S
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X100-30S Adjustable Stroke Cylinder Specifications
- Model: SAUJ50X100-30S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable range: ±15 mm via external stopper)
- Adjustment mechanism: External mechanical stopper with locknut
- Operating pressure: 0.1–0.8 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Port size: PT1/4 (G1/4 optional)
- Mounting style: Standard AF foot mounting (ISO 15552 compatible)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy barrel, CR-Steel rod, NBR seals
- Weight: 2.5 kg (without accessories)
- Dimensions:
- Extended length: 260 mm
- Retracted length: 160 mm
- Body diameter: Ø60 mm
- Rod end thread: M16×1.5
Precision-adjustable industrial cylinder featuring a rugged anodized aluminum construction with corrosion-resistant chromium-plated piston rod. The SAUJ series combines position feedback capability (via optional magnetic piston) with manual stroke adjustment resolution of ±0.5mm. Designed for applications requiring repeatable positioning without complex control systems.
- Packaging machine stopper positioning
- CNC fixture clamping force adjustment
- Conveyor height adjustment systems
- Automated assembly tooling with variable stroke requirements
- Printing press roller engagement mechanisms
Operation note:
For optimal performance, lubricate guide bushings every 2,000 km of cumulative travel.
Maximum side load capacity: 150N at mid-stroke. Always lock adjustment screws with 3.5N·m torque after positioning.
| Property | Property Value |
|---|---|
| sku | SAUJ50X100-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
