Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-40
$73.47
Regular price
$80.97
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ50X100-40
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard pneumatic cylinder compliant with proprietary specifications;
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
Installation protocol:
Always perform stroke adjustment in depressurized state. Lubricate through air port using ISO VG32 hydraulic oil
before initial operation. Maintain minimum 20mm clearance around cushion adjustment screws for maintenance access.
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X100-40 Adjustable Cylinder Specifications
- Model Code: SAUJ50X100-40
- Cylinder Type: Double-acting adjustable stroke
- Bore Size: Ø50mm (ISO 6432 standard)
- Stroke Length: 100mm (adjustable within 0-100mm range)
- Operating Pressure: 0.1-0.9 MPa
- Cushioning Type: Adjustable pneumatic cushion (both ends)
- Mounting Style: Front flange/Foot mounting (MF1/MF2 compatible)
- Rod Thread: M16×1.5 external thread
- Ambient Temperature: -20℃ to 80℃
- Piston Speed: 50-750 mm/s (lubricated)
- Seal Material: NBR (Nitrile) with wear-resistant ring
- Body Material: Aluminum alloy (anodized surface)
- Rod Material: Chrome-plated carbon steel (HRC 35-42)
- Weight: 2.3 kg ±5% (excluding accessories)
- Dimensions:
- Total Length (retracted): 200mm
- Cylinder Outer Diameter: 56mm
- Mounting Foot Width: 60mm
- Port Size: G1/8 (dual ports on both ends)
Precision-adjustable pneumatic cylinder featuring micro-stroke tuning capability (±0.5mm repeat accuracy) through its unique mechanical stopper system. The enhanced cushioning mechanism reduces end-impact noise by 30% compared to standard models. Integrated mounting slots allow 360° position adjustment without disassembly.
Industrial Applications:
- Precision press-fit operations in electronics assembly
- Variable height positioning in CNC tool changers
- Adjustable clamping force systems in injection molding
- Material feeding mechanisms with stroke compensation
- Automated packaging line pressure control
Installation protocol:
Always perform stroke adjustment in depressurized state. Lubricate through air port using ISO VG32 hydraulic oil
before initial operation. Maintain minimum 20mm clearance around cushion adjustment screws for maintenance access.
WARNING: Do not exceed maximum side load capacity of 120N. When used in vertical orientation,
install external guide mechanism for loads exceeding 5kg. Regular lubrication every 500,000 cycles required.
| Property | Property Value |
|---|---|
| sku | SAUJ50X100-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
