Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-40S
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X100-40S Adjustable Cylinder Specifications
- Model: SAUJ50X100-40S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable range: 0-100 mm)
- Operating pressure: 0.15–1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (MF1)
- Port size: PT1/4 (G1/4 optional)
- Rod end thread: M16×1.5
- Ambient temperature: -20℃ to 80℃
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Seal material: NBR (Nitrile rubber)
- Weight: 2.8 kg ±5%
- Dimensions (L×W×H): 200×80×80 mm (extended length: 300 mm)
- Accuracy class: ISO 6432 compliant
- Lubrication: Pre-lubricated (Oil-free operation possible)
Precision-adjustable pneumatic cylinder featuring dual-position locking mechanism with ±0.5mm repeatability. The SAUJ series combines impact-resistant construction with a 360° rotatable auto-stop nut system, enabling millimeter-level stroke adjustment without disassembly. Includes magnetic piston version compatibility (sensor not included).
- Variable height positioning in assembly jigs
- Press-fit operations with adjustable depth control
- Packaging machine stopper adjustment systems
- Semiconductor handling equipment
- Modular conveyor height compensators
Installation tip:
Apply thread locker (medium strength) on adjustment nuts after final positioning.
Maintain 0.5-1mm clearance between stopper and cylinder head during adjustment.
Requires 5μm filtered air for optimal seal longevity.
| Property | Property Value |
|---|---|
| sku | SAUJ50X100-40S |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
