Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-50
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-50 Technical Details
- Model Code: SAUJ50X100-50
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 100 mm (adjustable range: 50-100 mm)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -10℃ to 80℃
- Cushioning type: Adjustable rubber buffer (front/rear)
- Mounting style: Basic type (no built-in mounts)
- Port size: Rc1/4 (G1/4 optional)
- Rod end thread: M16×1.5
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated carbon steel
- Seal type: NBR + PU combination
- Weight: 2.45 kg ±3%
- Dimensions (L×W×H): 200mm × 62mm × 62mm (at full extension)
- Max speed: 500 mm/s
- Lubrication: Pre-lubricated (Grease-free operation possible)
Precision-adjustable cylinder featuring a unique mechanical stopper system for millimeter-level positioning accuracy. The dual-scale markings (metric/imperial) on the barrel enable visual stroke confirmation. Anti-rotation design maintains orientation stability during partial stroke operations. Includes built-in magnetic sensor slots for position feedback devices.
- Variable height work platforms in assembly lines
- Clamping force adjustment in CNC jigs
- Material feeding systems with product size variations
- Printing press pressure control mechanisms
- Packaging machine product height compensation
Operation tip:
Always lock adjustment nuts with 5-7 N·m torque after setting stroke.
For partial stroke applications, maintain ≥20% of maximum stroke as safety margin.
| Property | Property Value |
|---|---|
| sku | SAUJ50X100-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
