Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-50S
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X100-50S Adjustable Cylinder Technical Details
- Full model: SAUJ50X100-50S
- Bore size: Ø50mm (1.97")
- Stroke: 100mm (3.94") adjustable
- Operation pressure: 0.05-0.9 MPa
- Cushioning type: External adjustable rubber bumper
- Piston rod thread: M16×1.5 (male)
- Mounting style: Front/rear threaded ends (ISO 15552 compatible)
- Port size: G1/8 (BSPP)
- Ambient temperature: -10℃ to 80℃
- Seal material: Polyurethane (NBR optional)
- Max thrust: 1,570N @0.63MPa
- Weight: 3.2kg (7.05lbs)
- Dimensions:
- Extended length: 269mm (10.59")
- Retracted length: 169mm (6.65")
- Body diameter: Ø63mm (2.48")
- Mounting hole spacing: 33mm×33mm (1.30"×1.30")
Heavy-duty double-acting cylinder with precision stroke adjustment mechanism. Features chromium-plated piston rod and aluminum alloy barrel with hard anodized finish. The 50S variant includes external locking nuts for position fixation after adjustment. Requires air lubrication for optimal performance.
- Press machine ejection systems
- Plastic injection molding clamping units
- Automated conveyor sorting gates
- Glass tempering furnace door actuators
- Die-casting machine core-pull mechanisms
Installation protocol:
Use anti-vibration washers when mounting to metal frames. Perform stroke adjustment
before pressurization. Lubricate through air port weekly with ISO VG32 turbine oil.
| Property | Property Value |
|---|---|
| sku | SAUJ50X100-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
