Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-75
$73.47
Regular price
$80.97
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ50X100-75
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard pneumatic cylinder compliant with proprietary specifications;
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
Operational guidance:
Always lubricate adjustment threads with silicone grease. Lock adjustment nuts in opposite directions to prevent vibration-induced loosening. Maximum side load: 30N. For vertical installations, use guide mechanisms when payload exceeds 5kg.
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X100-75 Adjustable Cylinder Specifications
- Model: SAUJ50X100-75
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50 mm
- Standard stroke: 100 mm
- Adjustment range: 0-75 mm (external stroke adjustment)
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Elastic buffer + adjustable cushion screw
- Mounting style: MF1 front flange / optional foot mounting (SAUJ-F)
- Port size: M14×1.5 (G1/8 adaptor available)
- Operating temperature: -20℃ to 80℃
- Seal material: NBR (nitrile rubber)
- Piston rod material: Chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Weight: 2.45 kg (excluding accessories)
- Dimensions:
- Extended length: 275 mm
- Retracted length: 175 mm
- Body diameter: Ø56 mm
- Mounting hole spacing: 60×60 mm
Precision-engineered adjustable stroke cylinder featuring a unique dual-lock mechanism for position retention. The SAUJ series combines stroke adjustability (via external threaded rod) with standard cylinder functionality, allowing mid-stroke stopping capability without additional valves. Anti-rotation design ensures stable load handling.
Typical Applications:
- Variable height positioning in packaging machinery
- Precision clamping with adjustable force in CNC fixtures
- Material handling systems requiring multiple stop points
- Automated assembly line tooling adjustments
- Press-fit operations with depth control
Operational guidance:
Always lubricate adjustment threads with silicone grease. Lock adjustment nuts in opposite directions to prevent vibration-induced loosening. Maximum side load: 30N. For vertical installations, use guide mechanisms when payload exceeds 5kg.
Maintenance:
Inspect cushion seals every 500,000 cycles. Use only ISO VG32 hydraulic oil for lubrication. Avoid using in environments with phosphate ester-based lubricants.
| Property | Property Value |
|---|---|
| sku | SAUJ50X100-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
