Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-75S
$77.20
Regular price
$84.70
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ50X100-75S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard pneumatic cylinder compliant with proprietary specifications;
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
Installation protocol:
Use locknuts (M5x0.8) to secure adjustment bolts after calibration.
Maintain 0.5-1mm gap between stopper and cylinder end cap during initial setup.
Requires weekly re-lubrication in high-cycle (>500,000 cycles/month) applications.
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50 Adjustable Stroke Cylinder SAUJ50X100-75S Technical Details
- Model Code: SAUJ50X100-75S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 100 mm (base) with ±7.5mm adjustment range
- Total stroke adjustment: 85-115 mm (via external stopper)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G1/8 (ISO standard)
- Mounting type: Basic MF1 flange (ISO 15552 compatible)
- Weight: 2.85 kg (without accessories)
- Dimensions:
- Extended length: 286 mm
- Retracted length: 186 mm
- Body diameter: Ø63 mm
- Rod diameter: Ø20 mm
- Seal material: NBR (Nitrile) standard (FKM optional)
- Temperature range: -20℃ to +80℃
- Protection class: IP40 (standard wiper)
- Lubrication: Pre-lubricated (DOP mist compatible)
High-precision stroke-adjustable cylinder featuring micrometer-style mechanical stoppers (±7.5mm fine tuning) for position calibration without disassembly. The anodized aluminum construction with chromium-plated piston rod ensures corrosion resistance in humid environments. Includes magnetic piston for sensor integration.
Industrial Applications:
- Variable clamping force fixtures in CNC machining centers
- Position-compensation systems for thermal expansion in die casting
- Adjustable ejector mechanisms in plastic injection molding
- Precision web tension control in printing/packaging lines
- Automated tool changers with position feedback
Installation protocol:
Use locknuts (M5x0.8) to secure adjustment bolts after calibration.
Maintain 0.5-1mm gap between stopper and cylinder end cap during initial setup.
Requires weekly re-lubrication in high-cycle (>500,000 cycles/month) applications.
| Property | Property Value |
|---|---|
| sku | SAUJ50X100-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | 100mm |
