Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X1000-10
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50 Adjustable Cylinder SAUJ50X1000-10 Technical Specifications
- Model Code: SAUJ50X1000-10
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 1000 mm (adjustable)
- Operating pressure: 0.1-0.9 MPa
- Operation mode: Pneumatic (air pressure)
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting: Standard MF1/MF2 front flange & rear foot mounting
- Port size: G1/8 (1/4" NPT optional)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy barrel, CRCA steel rod, NBR seals
- Weight: 5.8 kg ±2% (without accessories)
- Dimensions: 1100mm(L) × 68mm(W) × 68mm(H)
- Rod thread: M10×1.25 external thread
- Max theoretical force: 177N @0.63MPa (extending)
- Piston speed: 50-750 mm/s
- ISO standard: 15552 compliant
High-precision long-stroke cylinder with unique mechanical stroke adjustment mechanism featuring dual locknuts for position fixation. The anodized barrel surface provides enhanced wear resistance, while the chrome-plated piston rod ensures corrosion protection. Includes built-in magnet for position sensing compatibility.
- Packaging line product positioning gates
- Automotive welding fixture actuation
- LCD panel handling systems
- Plastic injection molding ejectors
- Long-span material transfer mechanisms
Installation note:
For full stroke applications exceeding 800mm, recommend using intermediate support guides.
Lubricate with ISO VG32 hydraulic oil through built-in lubrication ports every 500km of travel.
Avoid side load exceeding 15N·m during operation.
| Property | Property Value |
|---|---|
| sku | SAUJ50X1000-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
