Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X1000-100
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X1000-100 Adjustable Stroke Air Cylinder Specifications
- Model: SAUJ50X1000-100
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 1000 mm (maximum)
- Adjustment range: 0-100 mm (micro-adjustable via external stopper)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: Rubber bumper + adjustable hydraulic absorber
- Mounting style: Basic type (no built-in mounts)
- Port size: G1/4 (ISO standard)
- Operating temperature: -10℃ to 80℃
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal type: NBR seals with wear-resistant ring
- Weight: 6.8 kg (cylinder body only)
- Dimensions:
- Extended length: 1345 mm (max stroke)
- Retracted length: 345 mm
- Body diameter: Ø62 mm
- Rod diameter: Ø20 mm
High-precision adjustable cylinder featuring a unique dual-lock mechanical stopper system for millimeter-level positioning accuracy. The hardened piston rod and corrosion-resistant construction enable operation in harsh environments. Includes integrated shock absorption with tunable damping for smooth end-of-stroke deceleration.
- Variable height positioning in automotive assembly jigs
- Material handling systems requiring adjustable lift heights
- Press machine tooling with depth control requirements
- Packaging line product height adjustment mechanisms
- Plastic injection molding ejection systems
Installation note:
Requires periodic lubrication (ISO VG32 hydraulic oil recommended).
Maintain minimum 0.3 MPa pressure during adjustment operations.
For vertical installations, use rod-end support brackets (sold separately).
| Property | Property Value |
|---|---|
| sku | SAUJ50X1000-100 |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
