Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X1000-100S
$172.58
Regular price
$180.08
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ50X1000-100S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard pneumatic cylinder compliant with proprietary specifications;
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
Installation note:
Requires rigid mounting surface with flatness ≤0.1mm/m. Lubricate with ISO VG32 hydraulic oil
before initial operation. For vertical installations, use optional guide brackets (model GB-50S)
to prevent side loading. Maximum permissible lateral force: 150N.
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X1000-100S Adjustable Cylinder Specifications
- Model: SAUJ50X1000-100S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50mm
- Stroke length: 1000mm (adjustable in 1mm increments)
- Operating pressure: 0.1-0.9 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Front/rear flange (ISO 15552 standard)
- Port size: G1/4 (NPT1/4 optional)
- Temperature range: -20℃ to 80℃
- Piston rod material: Chrome-plated stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Weight: 5.8kg (excluding accessories)
- Dimensions:
- Body diameter: Ø50mm
- Retracted length: 1185mm
- Extended length: 2185mm
- Mounting flange width: 70mm
High-precision long-stroke cylinder with position-locking mechanism, featuring micrometer-grade stroke adjustment through its integrated stopper system. The hardened piston rod and double lip seals ensure durability in high-cycle applications. Includes magnetic piston for position sensing compatibility.
Typical Applications:
- Precision press machines with variable die heights
- Automated palletizing systems requiring adjustable reach
- Plastic injection molding ejector mechanisms
- Large-format CNC material handling equipment
- Solar panel production line positioning
Installation note:
Requires rigid mounting surface with flatness ≤0.1mm/m. Lubricate with ISO VG32 hydraulic oil
before initial operation. For vertical installations, use optional guide brackets (model GB-50S)
to prevent side loading. Maximum permissible lateral force: 150N.
| Property | Property Value |
|---|---|
| sku | SAUJ50X1000-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
