Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X1000-10S
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50 Adjustable Cylinder SAUJ50X1000-10S Technical Details
- Model: SAUJ50X1000-10S
- Type: Adjustable stroke double-acting cylinder
- Bore size: Ø50 mm
- Stroke: 1000 mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting: Basic type (axial foot mounting holes)
- Port size: Rc1/4 (G1/4 optional)
- Temperature range: -20℃ to 80℃
- Material: Aluminum alloy barrel, stainless steel rod
- Sensor type: Built-in magnetic switch (10S suffix indicates reed sensor)
- Weight: 9.8 kg ±2%
- Dimensions: 1180mm(L) × 70mm(W) × 70mm(H) (full extension)
High-precision industrial cylinder optimized for long-stroke applications requiring position feedback. Features dual adjustable pneumatic cushions for smooth deceleration and integrated magnetic sensors for position detection. The hard-anodized rod surface ensures wear resistance in continuous operation.
- Automated assembly line positioning systems
- Press machine ejection mechanisms
- Material handling conveyor gates
- Textile machinery tension control
- Automotive welding fixture actuators
Installation note:
Maintain 0.5-1mm alignment tolerance during mounting. Lubricate with ISO VG32 hydraulic oil
before initial operation. Stroke adjustment requires loosening both end lock nuts simultaneously.
| Property | Property Value |
|---|---|
| sku | SAUJ50X1000-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
