Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X1000-20
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50 Adjustable Cylinder SAUJ50X1000-20 Technical Details
- Model Code: SAUJ50X1000-20
- Type: ISO 15552 compliant adjustable stroke cylinder
- Bore Size: Ø50 mm
- Stroke: 1000 mm (adjustable via external stopper)
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting Style: Basic type (MF1) with standardized mounting dimensions
- Port Size: G1/8 (NPT optional)
- Piston Material: Anodized aluminum alloy
- Rod Material: Hard chrome-plated steel
- Seal Type: NBR seals (standard), optional FKM for high temp
- Weight: 5.8 kg (without accessories)
- Dimensions: 1180mm(L) × 50mm(Bore Ø) × 80mm(Mounting height)
- Protection Class: IP54 (standard wiper design)
- Lubrication: Pre-lubricated, compatible with ISO VG32 hydraulic oil
High-precision long-stroke cylinder featuring dual external mechanical stoppers (±5mm fine adjustment range) for position calibration. The corrosion-resistant construction with triple-layer chrome plating ensures durability in humid environments. Integrated magnet slot supports magnetic switch installation for position feedback.
- Automated palletizing systems requiring variable stroke control
- Woodworking CNC feed mechanisms
- Plastic injection molding ejector units
- Automotive assembly line positioning devices
- Solar panel cleaning robot actuators
Installation Guidelines:
Maintain ≤0.5mm/m alignment tolerance during mounting. For strokes >800mm,
recommend using intermediate support brackets (ASQ50 accessory). Lubricate
rod weekly in high-cycle applications (>500 cycles/hour).
| Property | Property Value |
|---|---|
| sku | SAUJ50X1000-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
