Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X1000-20S
$172.58
Regular price
$180.08
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ50X1000-20S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard pneumatic cylinder compliant with proprietary specifications;
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting. For vertical installations exceeding 500mm stroke,
use auxiliary guide mechanisms. Lubricate rod weekly in high-cycle applications (＞500 cycles/day).
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50 Adjustable Cylinder SAUJ50X1000-20S Technical Specifications
- Model Code: SAUJ50X1000-20S
- Bore Size: Ø50 mm (ISO 6432 standard)
- Stroke Length: 1000 mm (adjustable via external stopper)
- Mounting Type: 20S series foot-mounted with reinforced base
- Operating Pressure: 0.15-0.8 MPa (21.7-116 PSI)
- Cushioning: Adjustable pneumatic cushion at both ends
- Temperature Range: -20℃ to +80℃ (NBR seals)/-10℃ to +60℃ (PU seals)
- Port Size: PT1/4 (G1/4 optional)
- Piston Speed: 50-750 mm/s (lubricated condition)
- Rod Thread: M16×1.5 (external)
- Protection Class: IP54 (standard wiper design)
- Material: Aluminum alloy barrel, chrome-plated piston rod
- Weight: 5.8 kg ±3% (excluding accessories)
- Dimensions: 1100mm(L) × 80mm(W) × 100mm(H) (full extension)
High-precision long-stroke cylinder with position-lock mechanism, featuring dual-axis adjustable stoppers (resolution: ±0.5mm) for micro-positioning. The 20S mounting base includes vibration-damping rubber pads and 4×M8 mounting holes (8mm depth). Requires 5μm filtered air with ISO VG32 lubricator oil (optional oil-free operation).
Industrial Applications:
- Automated palletizing systems (box height adjustment)
- Plastic injection molding machine ejectors
- Paper converting equipment tension control
- Automotive welding fixture positioning
- Solar panel production line alignment
Installation guidelines:
Maintain 0.05mm/m alignment tolerance during mounting. For vertical installations exceeding 500mm stroke,
use auxiliary guide mechanisms. Lubricate rod weekly in high-cycle applications (＞500 cycles/day).
Optional Accessories:
- Magnetic sensor kit: D-M9N (non-contact type)
- Rod lock nut: SNS-16 (stainless steel)
- Heat shield sleeve: HS-50 (300℃ rated)
| Property | Property Value |
|---|---|
| sku | SAUJ50X1000-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
