Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X1000-30S
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X1000-30S Adjustable Stroke Cylinder Specifications
- Model: SAUJ50X1000-30S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 1000 mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Cushion type: Air cushion + external shock absorber (30S option)
- Mounting type: Basic type (no built-in mounting features)
- Piston rod diameter: Ø20 mm
- Max thrust: 1960N @1.0MPa (extending)
- Temperature range: -20℃ to 80℃
- Air supply: Lubricated or non-lubricated (requires initial lubrication)
- Port size: G1/2 (ISO228/1 standard)
- Body material: Aluminum alloy (anodized)
- Rod material: Chrome-plated carbon steel
- Seal material: NBR + PU hybrid
- Weight: 9.8 kg ±2%
- Dimensions (L×W×H):
- Total length: 1295 mm (max extended)
- Body diameter: Ø62 mm
- Mounting base: 50×50 mm square profile
High-precision long-stroke cylinder with mechanical stroke adjustment locknuts, featuring dual shock absorption (internal air cushion + optional external buffers). The 30S variant includes reinforced rod bearings for heavy side load applications. Requires 5-40μm filtered air and monthly lubrication intervals under continuous operation.
- Automated pallet stacking systems
- Plastic injection molding ejectors
- Large-format CNC press brakes
- Solar panel production line positioning
- Automotive assembly line lifting arms
Installation note:
Requires horizontal mounting alignment within ±2° deviation. For vertical installations,
add external guide mechanisms. Allow 15mm thermal expansion clearance at both ends.
| Property | Property Value |
|---|---|
| sku | SAUJ50X1000-30S |
| Adjustable Stroke | 30mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
