Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X1000-40
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50 Adjustable Stroke Cylinder SAUJ50X1000-40 Technical Details
- Model Code: SAUJ50X1000-40
- Cylinder Type: Adjustable stroke, double-acting
- Bore size: Ø50 mm
- Stroke length: 1000 mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Cushioning: External adjustable rubber bumper
- Mounting style: MF40 (front flange with mounting holes)
- Operating temperature: -20℃ to 80℃
- Port size: Rc1/4 (NPT1/4 optional)
- Rod material: Hard chrome-plated carbon steel
- Tube material: Aluminum alloy with hard anodization
- Weight: 7.8 kg (without accessories)
- Dimensions: 1080mm(L) × 80mm(Ø) × 60mm(W)
- Rod thread: M16×1.5
- Piston speed: 50-800 mm/s
- ISO standard: 15552 compliant
High-precision industrial cylinder featuring patented position-lock mechanism for stroke adjustment. The extended 1000mm stroke version incorporates dual guide rods for enhanced stability. Includes wear-resistant seals (PU/NBR composite) and anti-rotation piston rod. Requires 5μm filtered air with lubrication (ISO VG32 recommended).
- Automated pallet stacking systems
- Large-format CNC machine tool clamping
- Automotive assembly line positioning
- Packaging line product ejection
- Solar panel frame pressing equipment
Installation guidelines:
Maintain 0.1mm/m alignment tolerance during mounting. For vertical installations,
use auxiliary support brackets every 600mm. Adjust cushioning screws clockwise
to increase damping force (max 1.5 turns from fully closed position).
Critical note:
Maximum side load capacity 120N. Exceeding this limit requires
additional guide mechanism. Not suitable for vacuum applications.
| Property | Property Value |
|---|---|
| sku | SAUJ50X1000-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
