Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X1000-50
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50 Adjustable Stroke Cylinder SAUJ50X1000-50 Technical Details
- Model Code: SAUJ50X1000-50
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø50 mm
- Stroke: 1000 mm (adjustable within 0-100% stroke)
- Adjustment range: ±5 mm fine-tuning via external stop screws
- Operating pressure: 0.1-0.9 MPa
- Cushioning: Adjustable rubber buffer (both ends)
- Mounting style: MF1 (Standard square flange)
- Port size: Rc1/4 (NPT1/4 optional)
- Temperature range: -10℃ to 80℃
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated stainless steel (SUS304)
- Seals: NBR + PU combination
- Weight: 8.7 kg (with standard accessories)
- Dimensions:
- Extended length: 1295 mm
- Retracted length: 295 mm
- Body diameter: Ø62 mm
- Mounting hole spacing: 80×80 mm
High-precision long-stroke cylinder featuring mechanical stroke adjustment with locking nuts, designed for heavy-duty applications requiring millimeter-level positioning accuracy. The dual chrome-plated piston rod enhances lateral load capacity, while the integrated cushioning mechanism reduces end-impact noise to ≤70 dB(A). Includes wear-resistant guide bands for smooth operation under 0.3 m/s speed.
- Palletizing robot end-effector positioning
- Automotive welding fixture height adjustment
- Glass panel cutting machine stopper control
- Textile machinery tension rod actuation
- Die casting machine ejector systems
Installation guidelines:
Requires minimum 20mm parallel alignment tolerance. Lubricate with ISO VG32 hydraulic oil
before initial use. Avoid side load exceeding 150N. For vertical mounting, install rod-end support bracket (optional accessory ASF50).
| Property | Property Value |
|---|---|
| sku | SAUJ50X1000-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
