Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X1000-75
$168.86
Regular price
$176.36
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ50X1000-75
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. Enterprise-standard pneumatic cylinder compliant with proprietary specifications;
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
Installation guidelines:
Maximum side load ≤15% of thrust rating. Use alignment couplers when
stroke exceeds 800mm. Apply thread locker (medium strength) to adjustment
bolts after final positioning.
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50X1000-75 Adjustable Cylinder Technical Details
- Full model: SAUJ50X1000-75
- Series: SAUJ Adjustable Stroke Cylinder
- Bore size: Ø50mm
- Stroke length: 1000mm (adjustable)
- Adjustment range: ±75mm (total 150mm stroke adjustment)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-1000mm/s
- Cushioning: Adjustable rubber cushion (both ends)
- Mounting type: Basic type (no built-in mounts)
- Port size: G1/2 (ISO228/1 standard)
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized)
- Seal type: NBR + PU combination
- Ambient temperature: -10℃ to 80℃
- Weight: 12.8kg ±5%
- Dimensions (L×W×H):
- Extended length: 1410mm
- Retracted length: 410mm
- Body width: 70mm
- Mounting height: 50mm
- ISO certification: 6431, 15552 compliant
Heavy-duty stroke-adjustable cylinder with dual locking nuts for precise stroke setting. Features wear-resistant rod coating and multi-layered sealing system. The 75mm adjustment mechanism allows mid-stroke positioning without disassembly. Requires 40μm filtered air with lubricator (ISO VG32 recommended).
Industrial Applications:
- Automated palletizing systems (box height adjustment)
- Plastic injection molding ejectors
- Textile machinery tension control
- Automotive assembly line positioning gates
- Lumber processing feed mechanisms
Installation guidelines:
Maximum side load ≤15% of thrust rating. Use alignment couplers when
stroke exceeds 800mm. Apply thread locker (medium strength) to adjustment
bolts after final positioning.
Service interval:
Relubricate every 500km of cumulative travel. Inspect cushion seals
biannually under continuous operation. Torque limits: 25N·m for adjustment
nuts, 45N·m for mounting bolts.
| Property | Property Value |
|---|---|
| sku | SAUJ50X1000-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
