Airtac SAUJ50 Adjustable Stroke Cylinder SAUJ50X1000-75S
2. Features customized bilateral piston sealing configuration with compact dimensions and integrated oil reservoir design;
3. Utilizes octagonal cross-section aluminum barrel construction without tie rods, providing enhanced corrosion resistance. Integrated sensor mounting grooves on outer wall for simplified installation;
4. Compact cylinder bore and reduced body length compared to ISO 15662 standard cylinders under SAU series specifications;
5. Optimized cushioned stroke adjustment mechanism ensures smooth operation;
6. Full compatibility with SC series cylinder mounting accessories;
7. Engineered with high-temperature resistant sealing compounds for operational range of 0-150℃.
Category: Standard Cylinders | Brand: AIRTAC | Series: SAUJ50
AirTAC SAUJ50 Adjustable Cylinder SAUJ50X1000-75S Technical Details
- Model Code: SAUJ50X1000-75S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 50mm
- Stroke length: 1000mm (adjustable)
- Rod diameter: 20mm
- Operating pressure: 0.05-1.0 MPa
- Cushioning type: Adjustable pneumatic cushion (both ends)
- Mounting style: Basic type (optional flange/bracket)
- Ambient temperature: -20℃ to 80℃
- Piston speed: 50-1000mm/s
- Port size: G1/8 (NPT1/8 optional)
- Material:
- Tube: Aluminum alloy (hard anodized)
- Piston rod: Chrome-plated steel
- End caps: Die-cast aluminum
- Weight: 6.8kg ±2%
- Dimensions (L×W×H):
- Retracted length: 1125mm
- Extended length: 2125mm
- Body width: 70mm
- Mounting height: 75mm
High-precision long-stroke cylinder with dual adjustable cushions and position sensing capability. Features wear-resistant rod seals (PU material) and integrated magnet for proximity switch compatibility. The anodized surface treatment provides corrosion resistance in humid environments. Requires ISO 8573-1:2010 class 4 compressed air.
- Automated palletizing systems
- Plastic injection molding ejectors
- Automotive assembly line positioning
- Paper converting machinery
- Large-format CNC machine tool doors
Maintenance tip:
Lubricate with ISO VG32 hydraulic oil every 500km of cumulative travel.
Avoid lateral loads exceeding 30N to prevent rod deflection. Alignment tolerance: ±0.5° maximum.
| Property | Property Value |
|---|---|
| sku | SAUJ50X1000-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <50mm> |
| Stroke | <1000mm> |
