Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X100-50
$119.80
Regular price
$127.30
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ80X100-50
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAUJ80 Adjustable Cylinder (Enterprise Standard)
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
Installation guidelines:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations,
use anti-vibration brackets when stroke exceeds 80mm. Lubricate guide shafts
every 500km of cumulative travel.
Critical notes:
Not suitable for side load applications exceeding 150N. Requires 40μm filtered
air with dew point -20℃ below ambient temperature. Maximum lateral force: 1/20
of piston thrust capacity.
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
AirTAC SAUJ80X100-50 Adjustable Cylinder Technical Details
- Full model: SAUJ80X100-50
- Series: SAUJ (Adjustable Stroke Compact Cylinder)
- Bore size: 80mm
- Stroke: 100mm (adjustable via external stopper)
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (5-50mm)
- Mounting type: Standard AF/FC options (foot & front flange)
- Port size: G3/8 (BSPP thread)
- Piston material: Aluminum alloy with hard anodizing
- Rod material: Chrome-plated steel (Cr-Mo)
- Seal type: NBR + PU combination seals
- Weight: 4.2kg (dry), 4.35kg (with standard accessories
- Dimensions: 326mm(L) × 100mm(W) × 100mm(H)
- Protection class: IP54 (standard), IP67 optional
- Lubrication: Pre-lubricated (DOP-free grease)
High-precision adjustable stroke cylinder featuring dual-position locking mechanism with ±0.5mm repeatability. The chrome-plated piston rod incorporates a wear-resistant coating (HV≥800) for extended service life. Integrated shock absorption system reduces end-impact noise by 15dB compared to standard models.
Industrial Applications:
- Variable height positioning in automated assembly lines
- Clamping force adjustment in CNC fixture systems
- Packaging machine stroke compensation mechanisms
- Material handling equipment with variable reach
- Plastic injection molding ejector systems
Installation guidelines:
Maintain 0.5-1mm alignment tolerance during mounting. For vertical installations,
use anti-vibration brackets when stroke exceeds 80mm. Lubricate guide shafts
every 500km of cumulative travel.
Critical notes:
Not suitable for side load applications exceeding 150N. Requires 40μm filtered
air with dew point -20℃ below ambient temperature. Maximum lateral force: 1/20
of piston thrust capacity.
| Property | Property Value |
|---|---|
| sku | SAUJ80X100-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
