Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X100-50S
$125.38
Regular price
$132.88
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ80X100-50S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAUJ80 Adjustable Cylinder (Enterprise Standard)
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
Adjustment procedure:
Loosen the lock nut (M12) using a 19mm wrench, rotate the stroke adjustment screw (clockwise to reduce stroke),
then re-tighten to 25±3 N·m torque. Always perform adjustment in depressurized state.
Critical note:
Maximum side load capacity 150N. For eccentric loads exceeding 50N,
mandatory use of external guide mechanism is required.
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
AirTAC SAUJ80X100-50S Adjustable Stroke Cylinder Specifications
- Model: SAUJ80X100-50S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 80mm
- Standard stroke: 100mm (adjustable range: 50-100mm)
- Operating pressure: 0.1–1.0 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting style: MF1 series square flange (ISO 15552 standard)
- Port size: PT1/2 (G1/2 optional)
- Piston rod material: Chrome-plated carbon steel (S45C)
- Cylinder tube: Hard anodized aluminum alloy
- Seal material: NBR with wear-resistant ring
- Temperature range: -20℃ to 80℃
- Max. piston speed: 500 mm/s
- Weight: 5.2 kg (excluding accessories)
- Dimensions:
- Body diameter: 80mm
- Retracted length: 242mm
- Extended length: 342mm
- Mounting flange: 125mm × 125mm
High-precision adjustable stroke cylinder featuring a unique mechanical lock mechanism for stroke adjustment. The SAUJ series incorporates dual-scale position indicators (metric/imperial) on the rod cover and an anti-rotation guide for stable linear motion. Requires ISO VG32 hydraulic oil or equivalent lubrication.
Typical Applications:
- Variable height positioning in automotive assembly jigs
- Press-fit tooling with depth control requirements
- Packaging line product height adjustment systems
- Semiconductor wafer handling equipment
- Die-casting machine ejection force control
Adjustment procedure:
Loosen the lock nut (M12) using a 19mm wrench, rotate the stroke adjustment screw (clockwise to reduce stroke),
then re-tighten to 25±3 N·m torque. Always perform adjustment in depressurized state.
Critical note:
Maximum side load capacity 150N. For eccentric loads exceeding 50N,
mandatory use of external guide mechanism is required.
| Property | Property Value |
|---|---|
| sku | SAUJ80X100-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | 100mm |
