Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X1000-100S
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
AirTAC SAUJ80X1000-100S Adjustable Cylinder Specifications
- Model: SAUJ80X1000-100S
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø80mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.05–0.8 MPa
- Temperature range: -20℃ to 80℃
- Cushioning: Adjustable hydraulic shock absorber (front/rear)
- Mounting style: MF1 front flange with rear foot mounting
- Port size: G1/2 (BSPP thread)
- Rod end thread: M45×1.5
- Material:
- Tube: Aluminum alloy hard anodized
- Piston rod: Chrome-plated carbon steel
- Seals: NBR (nitrile rubber)
- Weight: ~15.8kg (without accessories)
- Dimensions:
- Extended length: 1325mm (max)
- Retracted length: 325mm
- Width (flange): 125mm
- Height (mounting base): 90mm
High-precision industrial cylinder with unique dual-stage cushioning system, featuring micrometer-style stroke adjustment (±5mm fine tuning). The SAUJ80 series combines heavy-duty construction with 0.1mm positioning repeatability, ideal for long-stroke applications requiring controlled deceleration. Includes wear-resistant scraper seal for contaminated environments.
- Automotive assembly line positioning jigs
- Sheet metal press feeding systems
- Plastic injection molding ejectors
- Warehouse vertical lift actuators
- Steel mill roller alignment mechanisms
Installation tip:
Maintain 0.5-1mm clearance between cushion needle valve and end cover during adjustment.
Lubricate with ISO VG32 hydraulic oil. Avoid side load exceeding 50N during operation.
| Property | Property Value |
|---|---|
| sku | SAUJ80X1000-100S |
| Adjustable Stroke | 100mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | <1000mm> |
