Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X1000-75
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
AirTAC SAUJ80 Adjustable Cylinder SAUJ80X1000-75 Technical Specifications
- Model Code: SAUJ80X1000-75
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø80 mm
- Stroke: 1000 mm (adjustable)
- Operating pressure: 0.1-1.0 MPa
- Cushioning: Adjustable pneumatic cushion (both ends)
- Port size: G3/8
- Piston rod material: Chrome-plated steel (Ø25mm)
- Cylinder tube: Aluminum alloy with hard anodized surface
- Seal material: NBR + PU hybrid seals
- Ambient temperature: -20℃ to +80℃
- Weight: 9.8 kg (excluding accessories)
- Dimensions: 1205mm(L) × 100mm(W) × 100mm(H)
- Mounting type: Front flange (ISO 15552 standard)
- Repeat positioning accuracy: ±0.5mm
- Max thrust: 5024N @0.63MPa
High-precision long-stroke cylinder featuring mechanical stroke adjustment mechanism with locking nuts. The dual cushioning system minimizes end-impact noise while maintaining positioning stability. Integrated magnet slot for sensor mounting enables position feedback in automated systems. Corrosion-resistant construction with IP67 rating for harsh environments.
- Automated material handling systems
- Press machine ejection mechanisms
- Automotive assembly line positioning
- Packaging machine product pushers
- Plastic injection molding machine core pulls
Installation note:
Ensure proper alignment of guide rails when used in vertical orientation.
Lubricate through air port using ISO VG32 hydraulic oil.
Allow 50mm clearance at adjustment end for stroke modification.
| Property | Property Value |
|---|---|
| sku | SAUJ80X1000-75 |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | Non-magnetic |
| Bore Diameter | 80 mm |
| Stroke | <1000mm> |
