Airtac SAUJ80 Adjustable Stroke Cylinder SAUJ80X1000-75S
$312.88
Regular price
$320.38
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SAUJ80X1000-75S
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
SAUJ80 Adjustable Cylinder (Enterprise Standard)
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
Installation note:
Maintain 0.5mm minimum clearance between stopper nuts during adjustment.
Lubricate with ISO VG32 oil every 500km of cumulative travel. Avoid side load exceeding 150N.
Classification: Standard Cylinders | Brand: AirTAC | Series: SAUJ80
1. Enterprise-standardized cylinder design;
2. Asymmetric bidirectional sealing structure for piston with integrated oil reservoir, achieving compact dimensions;
3. Cross-ribbed aluminum tube construction (rodless design) with enhanced corrosion resistance. External surface features sensor mounting grooves for simplified installation;
4. Compact length design compared to ISO 15662 standard cylinders within the SAU bore series;
5. Progressive cushioning adjustment mechanism for smooth stroke termination;
6. Full compatibility with SC series cylinder mounting accessories;
7. High-temperature resistant sealing materials enable operational range: 0~150°C.
Key innovations: Optimized space efficiency through length reduction vs ISO standards, dual-purpose lubrication retention system, and cross-reinforced aluminum body for structural integrity.
AirTAC SAUJ80X1000-75S Adjustable Cylinder Specifications
- Model: SAUJ80X1000-75S
- Type: Double-acting adjustable stroke cylinder with auto-switch groove
- Bore size: 80 mm
- Stroke: 1000 mm (adjustable)
- Operating pressure: 0.05–1.0 MPa
- Cushioning type: Adjustable hydraulic buffer (both ends)
- Mounting style: Basic type (MF1) with optional flange/bracket mounts
- Port size: G1/2 (BSPP thread)
- Piston rod material: Chrome-plated carbon steel (JIS S45C)
- Tube material: Anodized aluminum alloy
- Seal material: NBR + PU combination
- Ambient temperature: -20℃ to 80℃
- Weight: 12.8 kg ±5%
- Dimensions (L×W×H):
- Extended length: 1345 mm
- Retracted length: 345 mm
- Body width: 105 mm
- Mounting height: 95 mm
- ISO standard: 15552 compliant
- Protection class: IP54 (standard), IP67 optional
High-precision industrial cylinder featuring dual adjustable stroke control through mechanical stoppers and hydraulic cushioning. The 75S variant includes reinforced rod bearings for heavy lateral load applications. Requires ISO VG32 hydraulic oil for buffer adjustment and supports magnetic piston detection (sensors not included).
Typical Applications:
- Automated material handling systems requiring variable stroke lengths
- Press machine ejection mechanisms
- Automotive assembly line positioning arms
- Large-format CNC machine tool clamping
- Packaging line product height adjustment stations
Installation note:
Maintain 0.5mm minimum clearance between stopper nuts during adjustment.
Lubricate with ISO VG32 oil every 500km of cumulative travel. Avoid side load exceeding 150N.
| Property | Property Value |
|---|---|
| sku | SAUJ80X1000-75S |
| Adjustable Stroke | 75mm |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT3/8 |
| Magnet | S-Magnetic |
| Bore Diameter | 80 mm |
| Stroke | <1000mm> |
