Airtac SDAD Double Rod Slim Cylinder SDAD100X110B
2. Features rivet-fastened barrel/rear cover assembly and piston/rod integration for structural integrity;
3. Barrel bore undergoes precision roller burnishing followed by hard-anodized surface treatment, ensuring superior wear resistance and operational longevity;
4. Asymmetric dual-lip piston seal configuration with integrated lubrication pockets optimizes compactness while maintaining sealing reliability;
5. Ultra-slim profile design minimizes spatial footprint for constrained installations;
6. Machined sensor grooves along barrel periphery enable simplified proximity switch integration;
7. Multiple mounting variants and stroke configurations available for application versatility.
Category: Double Rod Cylinders | Brand: AirTAC | Series: SDAD
AirTAC SDAD100X110B Double Rod Compact Cylinder Specifications
- Model: SDAD100X110B
- Type: Double-acting, dual rod compact cylinder
- Bore size: 100mm
- Stroke: 110mm (±55mm each side)
- Operating pressure: 0.1-0.9 MPa
- Medium temperature: -20℃ to 80℃
- Cushioning: Adjustable buffer (both ends)
- Mounting style: Basic type (optional foot/mounting flange)
- Port size: G3/8 (standard) / NPT1/2 (optional)
- Piston rod material: Hard chrome-plated carbon steel
- Seal material: NBR + PU combination
- Protection rating: IP54 (standard) / IP67 (optional)
- Weight: 2.3kg (excluding accessories)
- Dimensions: 230mm(L) × 118mm(W) × 118mm(H)
Ultra-slim profile cylinder (only 42mm height reduction vs standard models) with symmetrical dual rod design for balanced force distribution. Features wear-resistant guide bushings and multi-layered sealing system. Compatible with magnetic sensors (sensor slot integrated). Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- High-speed pick-and-place systems in electronics assembly
- Precision clamping mechanisms for CNC fixtures
- Bidirectional actuation in packaging machinery
- Material transfer gates in automated warehouses
- Robotic arm end-effector positioning
Installation note:
Maintain parallel alignment of dual rods during mounting. Lubricate with ISO VG32 hydraulic oil
before initial operation. Avoid lateral loading exceeding 30N. For vertical installations,
use guide brackets (sold separately).
| Property | Property Value |
|---|---|
| sku | SDAD100X110B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 100mm |
| Stroke | 110mm |
