Airtac SDAD Double Rod Slim Cylinder SDAD100X120SB
2. Features rivet-fastened barrel/rear cover assembly and piston/rod integration for structural integrity;
3. Barrel bore undergoes precision roller burnishing followed by hard-anodized surface treatment, ensuring superior wear resistance and operational longevity;
4. Asymmetric dual-lip piston seal configuration with integrated lubrication pockets optimizes compactness while maintaining sealing reliability;
5. Ultra-slim profile design minimizes spatial footprint for constrained installations;
6. Machined sensor grooves along barrel periphery enable simplified proximity switch integration;
7. Multiple mounting variants and stroke configurations available for application versatility.
Category: Double Rod Cylinders | Brand: AirTAC | Series: SDAD
AirTAC SDAD100X120SB Double Rod Compact Cylinder Specifications
- Model: SDAD100X120SB
- Type: Double-acting, dual rod compact cylinder
- Bore size: 100mm
- Stroke: 120mm
- Operating pressure: 0.1–0.9 MPa
- Operating temperature: -20℃ to 80℃
- Port thread: G3/8 (NPT1/4 optional)
- Cushioning: Adjustable rubber buffer (both ends)
- Rod material: Hard chrome-plated carbon steel
- Cylinder tube: Aluminum alloy with hard anodized finish
- Seal material: NBR (Nitrile rubber)
- Protection rating: IP65 (standard wiper design)
- Weight: 3.85 kg (±2%)
- Dimensions:
- Total length: 340mm (stroke-dependent)
- Body width: 100mm
- Height with rods: 152mm
- Mounting hole spacing: 80mm × 80mm
Ultra-flat profile cylinder (only 100mm width) with symmetrical dual rod configuration enables balanced force output and precise linear motion. Features corrosion-resistant construction with integrated magnetic sensor slots (non-inductive models available). Requires 5μm filtered air with ISO VG32 lubricant recommendation.
- Precision alignment systems in semiconductor manufacturing
- Synchronized clamping mechanisms in injection molding
- Vertical lifting platforms with space constraints
- Automated packaging line pusher mechanisms
- Parallel gripper configurations in robotics
Installation tip:
Maintain 0.1-0.3mm clearance between rods during parallel installations.
Use anti-rotation brackets (sold separately) for vertical mounting orientations.
| Property | Property Value |
|---|---|
| sku | SDAD100X120SB |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | S-Magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 100mm |
| Stroke | 120mm |
