Airtac SDAD Double Rod Slim Cylinder SDAD100X130B
2. Features rivet-fastened barrel/rear cover assembly and piston/rod integration for structural integrity;
3. Barrel bore undergoes precision roller burnishing followed by hard-anodized surface treatment, ensuring superior wear resistance and operational longevity;
4. Asymmetric dual-lip piston seal configuration with integrated lubrication pockets optimizes compactness while maintaining sealing reliability;
5. Ultra-slim profile design minimizes spatial footprint for constrained installations;
6. Machined sensor grooves along barrel periphery enable simplified proximity switch integration;
7. Multiple mounting variants and stroke configurations available for application versatility.
Category: Double Rod Cylinders | Brand: AirTAC | Series: SDAD
AirTAC SDAD Double Rod Compact Cylinder SDAD100X130B Technical Details
- Model: SDAD100X130B
- Type: Double rod compact cylinder (ISO 6432 compliant)
- Bore size: Ø100 mm
- Stroke: 130 mm (customizable 25-300 mm)
- Operating pressure: 0.05-1.0 MPa
- Operating temperature: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (both ends)
- Mounting types: MF1 (front flange) / MA3 (side lug) optional
- Port size: G3/8 (NPT1/4 optional)
- Piston rod thread: M16×1.5 (both ends)
- Material: Aluminum alloy body, chrome-plated steel rod
- Seals: NBR standard (PU or FKM available)
- Weight: 4.8 kg (without accessories)
- Dimensions: 296mm(L) × 118mm(W) × 118mm(H)
- Protection class: IP65 (wipers included)
Ultra-slim profile cylinder (30% thinner than standard models) with dual rod configuration for balanced force transmission. Features integrated magnet for position sensing and double lip seals for maintenance-free operation. Requires 40μm filtered compressed air with lubrication (ISO 8573-1 class 4).
- High-precision alignment in semiconductor handling
- Simultaneous clamping in CNC fixture systems
- Vertical lifting mechanisms in packaging lines
- Bidirectional actuation in automated test equipment
Installation note:
Maximum side load 15% of theoretical thrust. Use alignment couplers when
stroke accuracy <±0.5mm required. Lubricate rod weekly in high-cycle (>500k/yr) applications.
| Property | Property Value |
|---|---|
| sku | SDAD100X130B |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | PT3/8 |
| Piston Rod Thread Type | External Thread |
| Magnet | Non-magnetic |
| Cushion Type | Bumper Pad |
| Bore Diameter | 100mm |
| Stroke | 130mm |
