Airtac SEJ Adjustable Cylinder SEJ32BX80-10S
2. Asymmetric bidirectional piston seal structure with compact dimensions and integrated oil reservoir function;
3. Rodless square aluminum tubing construction enhances corrosion resistance;
4. Adjustable cushioning mechanism ensures smooth stroke modulation;
5. Customizable configurations with multiple cylinder variants and mounting accessories;
6. High-temperature resistant sealing materials enable operational range of 0-150°C.
Category: Adjustable Cylinders | Brand: AirTAC | Series: SEJ
AirTAC SEJ Adjustable Cushion Cylinder SEJ32BX80-10S Technical Specifications
- Model: SEJ32BX80-10S
- Type: Double-acting adjustable cushion cylinder
- Bore size: 32mm
- Stroke: 80mm (±1.5mm tolerance)
- Operating pressure: 0.05–1.0 MPa
- Cushion type: External adjustable (both ends)
- Port size: Rc1/8 (G1/8 optional)
- Mounting style: Basic type (axial foot mounting holes)
- Rod material: Hard chrome-plated steel
- Tube material: Aluminum alloy (anodized)
- Piston seal: NBR + PU hybrid seals
- Temperature range: -10℃ to 80℃
- Weight: 1.8kg (including rod)
- Dimensions: 200mm(L) × 80mm(W) × 125mm(H)
- Rod thread: M12×1.25
- Max theoretical thrust: 201N @ 0.63MPa
- Protection rating: IP54 (standard wiper design)
Precision-engineered cylinder featuring dual adjustable cushions for smooth stroke termination control. The chrome-plated piston rod resists scoring while the anodized barrel prevents corrosion. Integrated mounting lugs allow direct installation in vertical/horizontal orientations. Requires air lubrication for optimal seal performance.
- Precision positioning in CNC tool changers
- Material handling equipment requiring soft stops
- Packaging line clamping mechanisms
- Automated test fixture actuation
- Machine tool jig positioning systems
Operational note:
Adjust cushion screws while observing motion - clockwise rotation increases damping.
Lubricate through air supply (ISO VG32 recommended). Avoid side-load exceeding 15N.
| Property | Property Value |
|---|---|
| sku | SEJ32BX80-10S |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 80 mm |
