Airtac SEJ Adjustable Cylinder SEJ32X100-20S
2. Asymmetric bidirectional piston seal structure with compact dimensions and integrated oil reservoir function;
3. Rodless square aluminum tubing construction enhances corrosion resistance;
4. Adjustable cushioning mechanism ensures smooth stroke modulation;
5. Customizable configurations with multiple cylinder variants and mounting accessories;
6. High-temperature resistant sealing materials enable operational range of 0-150°C.
Category: Adjustable Cylinders | Brand: AirTAC | Series: SEJ
AirTAC SEJ Adjustable Stroke Cylinder SEJ32X100-20S Specifications
- Model: SEJ32X100-20S
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm
- Stroke: 100mm (±5mm adjustable range)
- Adjustment mechanism: External threaded stopper with lock nut
- Operating pressure: 0.05–1.0 MPa
- Port size: M5x0.8 (G1/8 optional)
- Cushion type: Rubber buffer + adjustable cushioning
- Mounting style: Basic type (Accessories: MFH, MFQ, MFP optional)
- Rod material: Chrome-plated stainless steel (SUS304)
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 1.8kg (including accessories)
- Dimensions:
- Extended length: 192mm (max)
- Retracted length: 92mm (min)
- Body diameter: 42mm
- Mounting hole spacing: 25mm x 25mm
Precision-adjustable pneumatic cylinder featuring micrometer-style stroke adjustment with ±5mm fine-tuning capability. The dual cushioning system minimizes end-impact noise while maintaining positioning accuracy (±0.5mm repeatability). Anti-rotation design ensures stable load-bearing with integrated mounting slots for flexible installation.
- Precision press-fit operations in electronic assembly
- Variable height positioning in CNC tool changers
- Adjustable clamping force systems
- Packaging line product height compensation
- Semiconductor wafer handling equipment
Operational note:
Always depressurize before adjusting stroke. Apply thread-locking compound (Loctite 243 recommended)
after final position setting. Lubricate with ISO VG32 turbine oil for high-cycle applications.
| Property | Property Value |
|---|---|
| sku | SEJ32X100-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | S-Magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 100mm |
