Airtac SEJ Adjustable Cylinder SEJ32X120-40
2. Asymmetric bidirectional piston seal structure with compact dimensions and integrated oil reservoir function;
3. Rodless square aluminum tubing construction enhances corrosion resistance;
4. Adjustable cushioning mechanism ensures smooth stroke modulation;
5. Customizable configurations with multiple cylinder variants and mounting accessories;
6. High-temperature resistant sealing materials enable operational range of 0-150°C.
Category: Adjustable Cylinders | Brand: AirTAC | Series: SEJ
AirTAC SEJ32X120-40 Adjustable Cylinder Specifications
- Model: SEJ32X120-40
- Bore size: 32 mm
- Stroke: 120 mm (adjustable)
- Operation type: Double-acting
- Adjustment mechanism: Manual stroke adjustment with lock nut
- Working pressure range: 0.05–1.0 MPa
- Cushioning: Adjustable pneumatic cushion at both ends
- Mounting type: Basic (non-magnetic) with standard ISO 6432 mounting pattern
- Rod end: Female thread M16×1.5
- Ambient temperature: -10℃ to 80℃
- Piston speed: 50–800 mm/s
- Seal material: NBR (nitrile rubber)
- Weight: 1.8 kg ±5%
- Dimensions: 230mm(L) × 50mm(W) × 50mm(H) (fully retracted)
- Stroke tolerance: ±1.5mm
- Air port size: G1/8
- Corrosion resistance: Chromium-plated piston rod
Precision-adjustable pneumatic cylinder featuring a unique mechanical locking mechanism for stroke calibration. The SEJ series combines position stability with impact absorption through dual adjustable cushions. Optimized for applications requiring repeatable positioning adjustments without disassembly. Requires 5-40μm filtered compressed air with ISO VG32 lubricant (optional oil-free operation).
- Variable-height material clamping systems
- Printing press roller gap adjustment
- Semiconductor wafer handling robots
- Automated packaging line stopper positioning
- Plastic injection mold core-pulling mechanisms
Installation note:
Align cylinder axis within ±0.5° angular misalignment. For vertical mounting,
use anti-vibration brackets when stroke exceeds 100mm. Perform stroke
calibration at 0.3MPa before full-pressure operation.
| Property | Property Value |
|---|---|
| sku | SEJ32X120-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 120mm |
