Airtac SEJ Adjustable Cylinder SEJ32X125-20
2. Asymmetric bidirectional piston seal structure with compact dimensions and integrated oil reservoir function;
3. Rodless square aluminum tubing construction enhances corrosion resistance;
4. Adjustable cushioning mechanism ensures smooth stroke modulation;
5. Customizable configurations with multiple cylinder variants and mounting accessories;
6. High-temperature resistant sealing materials enable operational range of 0-150°C.
Category: Adjustable Cylinders | Brand: AirTAC | Series: SEJ
AirTAC SEJ32X125-20 Adjustable Stroke Cylinder Specifications
- Model: SEJ32X125-20
- Type: Double-acting adjustable stroke cylinder
- Bore size: 32mm
- Stroke: 125mm (adjustable)
- Adjustment range: 0-20mm fine tuning via external screw
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃
- Cushion type: Rubber buffer (both ends)
- Mounting style: Basic type (optional foot/mounting flange)
- Port size: M5x0.8 (Rc1/8 adaptor included)
- Seal material: Polyurethane (NBR optional)
- Repeat positioning accuracy: ±0.5mm
- Max speed: 500mm/s
- Protection rating: IP54
- Weight: 1.8kg (excluding accessories)
- Dimensions: 200mm(L) × 50mm(W) × 50mm(H)
- Rod diameter: 12mm
- Mounting hole spacing: 40mm
Precision-adjustable pneumatic cylinder featuring a unique mechanical stopper system with graduated scale for visual feedback. The chrome-plated piston rod and anodized aluminum body ensure corrosion resistance in humid environments. Integrated cushioning adjustment allows soft end-of-stroke deceleration, reducing impact noise below 75dB.
- Precision workpiece positioning in automated assembly lines
- Variable height adjustment in packaging machinery
- Tooling fixture position fine-tuning
- Semiconductor handling equipment
- Printing press roller engagement systems
Installation note:
Lubricate with ISO VG32 hydraulic oil before initial operation.
For optimal performance, maintain 0.3-0.6 MPa working pressure
and avoid lateral loads exceeding 15N. Regular stopper screw
inspection (every 500km stroke) recommended.
| Property | Property Value |
|---|---|
| sku | SEJ32X125-20 |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
