Airtac SEJ Adjustable Cylinder SEJ32X125-40
2. Asymmetric bidirectional piston seal structure with compact dimensions and integrated oil reservoir function;
3. Rodless square aluminum tubing construction enhances corrosion resistance;
4. Adjustable cushioning mechanism ensures smooth stroke modulation;
5. Customizable configurations with multiple cylinder variants and mounting accessories;
6. High-temperature resistant sealing materials enable operational range of 0-150°C.
Category: Adjustable Cylinders | Brand: AirTAC | Series: SEJ
AirTAC SEJ Adjustable Stroke Cylinder SEJ32X125-40 Specifications
- Model: SEJ32X125-40
- Type: Double-acting adjustable stroke cylinder
- Bore size: Ø32 mm
- Stroke: 125 mm (adjustable)
- Rod diameter: Ø12 mm
- Operating pressure: 0.05-1.0 MPa
- Medium: Dry air (Lubricated or non-lubricated)
- Ambient temperature: -20℃ to 80℃
- Cushioning: Adjustable elastic cushion (both ends)
- Mounting type: Basic type (no pre-mounting accessories)
- Port size: M5x0.8 (Rc1/8, NPT1/8 optional)
- Material:
- Tube: Aluminum alloy, hard anodized
- Piston rod: Chrome-plated steel
- End caps: Die-cast aluminum
- Weight: 1.85 kg ±2%
- Dimensions:
- Extended length: 253 mm
- Retracted length: 128 mm
- Body width: 50 mm
- Mounting height: 32 mm
This precision adjustable stroke cylinder features micro-positioning capability through its unique mechanical stopper system, allowing ±1mm repeat positioning accuracy. The corrosion-resistant construction with integrated cushioning adjustment screws enables smooth end-of-stroke deceleration. Sealed with high-grade NBR seals for oil-free operation compatibility.
- Precision clamping fixtures in CNC machining centers
- Variable stroke press mechanisms in packaging lines
- Position-adjustable stops in automated assembly systems
- Material handling equipment requiring variable reach
- Semiconductor manufacturing positioning stages
- Use rigid mounting brackets to prevent misalignment
- Maintain 0.5-1mm clearance between stopper and cylinder end during adjustment
- For vertical installations, provide rod-end support when handling >5kg loads
- Lubricate with ISO VG32 turbine oil if using non-lubricated air
| Property | Property Value |
|---|---|
| sku | SEJ32X125-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature:-20-70°C Speed Range:30-800mm/s |
| Port Size | PT1/8 |
| Magnet | Non-magnetic |
| Bore Diameter | <32 mm> |
| Stroke | 125mm |
