Airtac SGCJ200-250 Adjustable Cylinder SGCJ200X100-10
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
AirTAC SGCJ200~250 Adjustable Cylinder SGCJ200X100-10 Technical Details
- Full Model: SGCJ200X100-10
- Series: SGCJ Adjustable Stroke Compact Cylinder
- Bore Size: Ø200mm
- Stroke: 100mm (adjustable through mechanical stops)
- Operating Pressure: 0.05-1.0 MPa
- Temperature Range: -20℃ to 80℃
- Cushioning: Adjustable pneumatic cushion (front/rear)
- Mounting Style: Basic MF1 (optional flange/clevis mounts)
- Port Size: G1-1/2 (standard), optional NPT/UNF
- Piston Speed: 50-750 mm/s
- Body Material: Aluminum alloy (hard anodized)
- Seal Material: NBR + Polyurethane hybrid seals
- Accessories: Built-in magnet for position sensing
- Weight: 18.6 kg (bare cylinder), 19.2 kg (with standard accessories)
- Dimensions:
- Length: 382mm (min. retracted)
- Width: 232mm (mounting face to rear cover)
- Height: 232mm (cylindrical body diameter)
High-torque industrial cylinder with precision stroke adjustment mechanism, featuring dual adjustable rubber cushions for shock absorption. The triple-seal design ensures leak-proof operation in high-cycle applications. Integrated wear-resistant guide bushing prevents piston rod deflection. Requires ISO 8573-1:2010 Class 3-4-3 compressed air.
- Press machine ejection systems
- Heavy-duty clamping fixtures
- Foundry equipment positioning
- Automotive chassis assembly jigs
- Industrial press brake tooling
Installation protocol:
Lubricate with ISO VG32 hydraulic oil before initial use.
Maintain 0.3-0.6 MPa pressure during adjustment screw operation.
Allow 15mm clearance around cushion screws for maintenance access.
| Property | Property Value |
|---|---|
| sku | SGCJ200X100-10 |
| Adjustable Stroke | <10mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
