Airtac SGCJ200-250 Adjustable Cylinder SGCJ200X100-20S
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
AirTAC SGCJ200X100-20S Adjustable Stroke Cylinder Specifications
- Series: SGCJ200~250 Adjustable Series
- Full model: SGCJ200X100-20S
- Bore size: 200mm
- Stroke: 100mm (adjustable)
- Operating pressure: 0.05-1.0 MPa
- Piston speed: 50-1000mm/s
- Cushion type: Air cushion adjustable (+5° cushion needle valve)
- Mounting style: Basic type (MF1) with foot mounting
- Rod end: External thread M45×2
- Magnet type: Built-in magnet for sensor mounting
- Seal material: Polyurethane (NBR optional)
- Temperature range: -20℃ to 80℃
- Weight: 29.8kg (excluding accessories)
- Dimensions:
- Total length: 656mm (min) / 756mm (max)
- Body diameter: 250mm
- Mounting base: 250×250mm
- Rod diameter: 45mm
- Air port size: G1-1/2
- Protection rating: IP54 (standard)
Heavy-duty adjustable stroke cylinder with precision positioning capability, featuring dual adjustable cushioning and oversized mounting base for stability. The 20S variant includes hardened chrome piston rod (HRC45-50) and wear-resistant guide rings. Requires ISO 8573-1:2010 [3:4:3] class compressed air.
- Die casting machine ejection systems
- Automotive press line material handling
- Steel coil positioning in rolling mills
- Injection molding machine clamp adjustment
- Paper mill roller gap control
Operation note:
Adjust stroke via external locknut (torque 120N·m max). Lubricate rod weekly with ISO VG32 hydraulic oil.
Magnetic sensor should be mounted within 2mm of cylinder body.
| Property | Property Value |
|---|---|
| sku | SGCJ200X100-20S |
| Adjustable Stroke | <20mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | 100mm |
