Airtac SGCJ200-250 Adjustable Cylinder SGCJ200X1000-40
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
AirTAC SGCJ200X1000-40 Adjustable Cylinder Specifications
- Series: SGCJ200~250 Adjustable Stroke
- Full model: SGCJ200X1000-40
- Bore size: 200mm
- Stroke: 1000mm (adjustable)
- Operating pressure: 0.05~1.0 MPa
- Cushioning type: External adjustable rubber bumper
- Mounting style: MS40 (Standard foot mounting)
- Rod end type: Female thread (M45×2)
- Piston material: Cast aluminum alloy with hard anodizing
- Rod material: Chrome-plated carbon steel
- Seal type: NBR + PU combination seals
- Temperature range: -20℃ to 80℃
- Max speed: 500mm/s
- Lubrication: Pre-lubricated (Grease-free operation)
- Weight: 28.5kg (dry)
- Dimensions: 1435mm(L) × 230mm(W) × 230mm(H)
Heavy-duty adjustable stroke cylinder with precision positioning capability, featuring dual-side adjustable cushioning for smooth deceleration. The oversized piston rod (45mm diameter) ensures high rigidity in long-stroke applications. Integrated mounting slots allow flexible installation configurations.
- Automotive assembly line positioning fixtures
- Sheet metal press ejection systems
- Plastic injection molding machine core-pull mechanisms
- Large-scale material handling gates
- Paper converting equipment actuators
Installation note:
Requires minimum 0.3mm/m alignment tolerance during mounting.
For full stroke operation, maintain 50mm clearance at both ends.
Lubricate guide rods monthly with ISO VG32 hydraulic oil.
| Property | Property Value |
|---|---|
| sku | SGCJ200X1000-40 |
| Adjustable Stroke | <40mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
