Airtac SGCJ200-250 Adjustable Cylinder SGCJ200X1000-50
$1,042.18
Regular price
$1,049.68
Sale!
Unit price
per
sold in last hours
customers are viewing this product
Couldn't load pickup availability
SKU:
In stock
SKU:
SGCJ200X1000-50
Product type:
DELIVERY
Estimated delivery between
and
Guarantee Safe Checkout
Description
1. ISO 15552 (formerly ISO 6431) standard-compliant cylinder;
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
Installation guidelines:
Requires horizontal mounting with maximum 0.1mm/m parallelism tolerance.
Use support brackets every 800mm for full stroke operation.
Lubricate guide rails with ISO VG32 hydraulic oil monthly in continuous operation.
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
AirTAC SGCJ200~250 Adjustable Stroke Cylinder (SGCJ200X1000-50) Technical Details
- Full model code: SGCJ200X1000-50
- Series: SGCJ Adjustable Stroke Series
- Bore size: 200mm (7.87")
- Stroke: 1000mm (39.37") ±2mm adjustable
- Operating pressure: 0.05-1.0 MPa
- Temperature range: -20℃ to 80℃ (non-freezing)
- Cushioning: External adjustable rubber bumper
- Mounting type: MF1 (Standard fixed mount with front flange)
- Port size: G1-1/2 (ISO 228/1)
- Piston rod thread: M45x1.5
- Tube material: Anodized aluminum alloy (AlMgSi1)
- Rod material: Hard chrome-plated 45# steel
- Seals: HNBR (Hydrogenated Nitrile) with wear-resistant ring
- Lubrication: Pre-lubricated (DOP oil), maintenance-free
- Protection class: IP54 (standard wiper design)
- Weight: 23.8kg (52.47 lbs) ±5%
- Dimensions (LxWxH):
- Body length: 1245mm (49.02")
- Overall width: 240mm (9.45")
- Mounting height: 280mm (11.02")
- Stroke tolerance: +1.5mm/-0mm
Heavy-duty adjustable stroke cylinder with precision stroke adjustment mechanism, featuring a dual-position locking system for stable positioning. The triple-sealed rod design ensures leak-proof operation in high-cycle applications. Includes impact-absorbing end caps and anti-rotation guide for alignment-critical installations.
Industrial Applications:
- Automotive press line material handling systems
- Large-format injection molding machine ejectors
- Steel coil handling equipment in rolling mills
- Paper converting machinery tension control
- Shipbuilding fixture positioning systems
Installation guidelines:
Requires horizontal mounting with maximum 0.1mm/m parallelism tolerance.
Use support brackets every 800mm for full stroke operation.
Lubricate guide rails with ISO VG32 hydraulic oil monthly in continuous operation.
| Property | Property Value |
|---|---|
| sku | SGCJ200X1000-50 |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | Non-magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
