Airtac SGCJ200-250 Adjustable Cylinder SGCJ200X1000-50S
2. SG series features dual Y-type unidirectional piston seals with compensation mechanism, ensuring extended service life and low starting pressure. SGC series adopts specialized bidirectional sealing structure with compact dimensions and integrated lubrication reservoir;
3. SG series utilizes steel tube construction for enhanced impact resistance;
4. SGC series employs aluminum tube design with optional magnetic sensing ring (not available for SG series);
5. Precision-adjustable pneumatic cushioning system for smooth operation;
6. Comprehensive selection of cylinder sizes and mounting accessories;
7. High-temperature resistant seals enable operational range of 0-150°C.
Category: Standard Cylinders | Brand: AirTAC | Series: SGCJ200~250 Adjustable Stroke Cylinder
AirTAC SGCJ200X1000-50S Adjustable Cylinder Specifications
- Series: SGCJ200~250 (ISO 15552 compliant)
- Model: SGCJ200X1000-50S
- Bore size: 200mm
- Stroke: 1000mm (adjustable)
- Operation type: Double-acting
- Working pressure: 0.05-1.2 MPa
- Piston speed: 50-1000 mm/s
- Cushioning type: Adjustable hydraulic buffer (both ends)
- Mounting style: MS50S (ISO 15552 front flange with integrated mounting holes)
- Port size: G3/4 (NPT 1" optional)
- Piston rod material: Hard chrome-plated carbon steel
- Tube material: Anodized aluminum alloy
- Seal material: NBR (Nitrile rubber)
- Temperature range: -20℃ to 80℃
- Weight: 48.5 kg ±2% (without accessories)
- Dimensions:
- Extended length: 1485mm
- Retracted length: 485mm
- Body diameter: 230mm
- Mounting flange width: 280mm
- Protection rating: IP65 (standard wiper seal)
- Lubrication requirement: ISO VG32 hydraulic oil (pre-lubricated)
Heavy-duty industrial cylinder designed for high moment load applications, featuring precision-ground rod and multi-layer sealing system. The hydraulic cushioning mechanism allows smooth deceleration adjustment through 16-position rotary valves at both ends. Integrated mounting flange enables secure installation in vertical/horizontal orientations.
- Automotive production line clamping fixtures
- Steel coil handling equipment
- Injection molding machine ejectors
- Shipbuilding alignment systems
- Hydraulic press auxiliary actuators
Installation note:
Use alignment jigs during mounting to prevent side load. For strokes over 800mm,
recommend adding intermediate support guides. Lubricate rod weekly in high-cycle
applications (>500 cycles/hour).
| Property | Property Value |
|---|---|
| sku | SGCJ200X1000-50S |
| Adjustable Stroke | <50mm> |
| Seal Material | Polyurethane |
| Understood. Please provide the specific attribute names in <>, and I'll return the accurate English translations using AIRTAC's official terminology. Example: User input: <缸径> My output: Bore | Operating Temperature: -20°C to 70°C Speed Range: 30 to 500 mm/s |
| Port Size | BSPT 3/4 |
| Magnet | S-Magnetic |
| Bore Diameter | <200mm> |
| Stroke | <1000mm> |
